Introduction to OSFP The OSFP is a new pluggable form factor with eight high speed electrical lanes that will initially support 400 Gbps (8x50G). It is slightly wider and deeper than the QSFP but it still supports 36 OSFP ports per 1U front panel, enabling 14.4 Tbps per 1U. Since the OSFP is slightly wider […]
CFP2-ACO Transceivers is a CFP2 Form factor with Analog Coherent Optics (ACO) techniques, this transceiver module is designed to support high density line card applications with the coherent Digital Signal Processor (DSP) on the host board.The CFP2-ACO provides broad applications, it can meet a large enough addressable market for the optical module vendors to amortize […]
Sound cable management practices help data centers function smoothly and reliably. Managers can implement a variety of procedures to minimize data center inefficiencies, such as slow troubleshooting and interruptions due to the unplugging the wrong equipment.) Well managed cable supports server performance and throughput, minimizes disruptions and downtime, and safeguards the integrity of cables and […]
Which fiber cable to use? Which value to measure? Which length to get? This fact sheet provides practical answers without devoting to the theoretical background. Started fiber optic cable for data installations with OM1, now there is already OM5. Started Ethernet over fiber with 100BaseLX, now there are dozens of different protocols. What does the […]
AOC (Active Optical Cables) and DAC (Direct Attach Cables are both preassembled modules with cable, they are used in the data center and enterprise networks, AOCs and DACs are plug and play, allowing the existing cabling resources to upgrade without installing new fiber optic normally the DACs and AOCs are with standard cable lengths and […]
Based on MSA (Multi-source agreement), The are many forms of fiber optic transceivers, each pluggable optical transceivers with different transmission distance options, it including form factors, such as the SFP, SFP+, XENPAK, QSFP, XFP, CFP etc.; GBIC – First generation transceivers with SC fiber interface, commonly used with Gigabiy Ethernet and fibre channel, also available […]
The enhanced small form-factor pluggable (SFP+) is an enhanced version of the SFP that supports data rates up to 16 Gbit/s. The SFP+ specification was first published on May 9, 2006, and version 4.1 published on July 6, 2009. SFP+ supports 8 Gbit/s Fibre Channel, 10 Gigabit Ethernet and Optical Transport Network standard OTU2. It […]
Before you install the MPO connectors in the data cnter, it is essential that all the fiber end-faces and the ferrule are really clean. especially when you thinking about lining up 12, 16, 24 or 32 pieces of 9um fibers in one or two rows, it requires tremendous precision. Any dirts in the mix on […]
The QSFP form factor is today’s industry workhorse for delivering 40 and 100GbE. The “Q” is for “quad” — a nod to the four-channel electrical interface, with each lane running at 25 Gbps for 100GbE. QSFP-DD adapts the same basic concept as its predecessor, but doubles the electrical contact density, via eight differential pairs capable […]
SFP-DD is short for SFP Double Densty, it is a new module and cage/connector system similar to current SFP module, but with an additional row of contacts providing for a two lane electrical interface. It is being developed by the SFP-DD MSA as a key part of the industry’s effort to enable high-speed solutions. The […]
